.690φ（17.45mm） T型电路标准系列
|
型号 |
图
号 |
额定电压 |
电流
Amp |
最小
电容量
μF |
最大
L
mm |
最小插入损耗（dB） |
|
85℃
DC | AC |
125℃
DC | AC |
30
KHz |
150
KHz |
300
KHz |
1
MHz |
10
MHz |
100
MHz |
1
GHz |
|
SCI-6140-004 |
1 |
150 |
--- |
100 |
--- |
1.00 |
2.600 |
30.353 |
23 |
54 |
70 |
70 |
70 |
70 |
70 |
|
SCI-6140-006 |
1 |
150 |
--- |
100 |
--- |
3.00 |
2.600 |
30.353 |
21 |
35 |
46 |
70 |
70 |
70 |
70 |
|
SCI-6140-007 |
1 |
150 |
--- |
100 |
--- |
5.00 |
2.600 |
30.353 |
21 |
34 |
41 |
58 |
70 |
70 |
70 |
|
SCI-6140-009 |
1 |
150 |
--- |
100 |
--- |
20.0 |
2.600 |
30.353 |
21 |
35 |
41 |
50 |
60 |
70 |
70 |
|
51-321-649 |
1 |
250 |
125 |
200 |
125 |
2.00 |
0.360 |
30.353 |
--- |
24 |
38 |
65 |
70 |
70 |
70 |
|
51-321-610 |
1 |
450 |
240 |
400 |
240 |
1.00 |
0.360 |
30.353 |
7 |
43 |
60 |
70 |
70 |
70 |
70 |
.690φ（17.45mm） T型电路军标认证系列
|
型号 |
M15733
军标号
|
图
号 |
额定电压 |
电流
Amp |
最小
电容量
μF |
最大
L
mm |
最小插入损耗（dB） |
|
85℃
DC|AC |
125℃
DC | AC |
30
KHz |
150
KHz |
300
KHz |
1
MHz |
10
MHz |
100
MHz |
1
GHz |
|
51-321-607 |
27-0017 |
1 |
--- |
--- |
200 |
125 |
1.50 |
0.250 |
30.353 |
--- |
19 |
32 |
62 |
70 |
70 |
70 |
|
51-321-608 |
27-0018 |
1 |
--- |
--- |
200 |
125 |
4.00 |
0.250 |
30.353 |
--- |
14 |
21 |
36 |
70 |
70 |
70 |
|
51-321-670 |
54-0017 |
2 |
--- |
--- |
300 |
115 |
10.0 |
0.500 |
29.896 |
5 |
20 |
23 |
35 |
60 |
70 |
60 |
.375φ（9.78mm）TT型电路标准系列
|
型号 |
图
号 |
额定电压 |
电流
Amp |
最小
电容量
μF |
最大
L
mm |
螺纹长度 |
最小插入损耗（dB） |
|
85℃
DC | AC |
125℃
DC | AC |
30
KHz |
150
KHz |
300
KHz |
1
MHz |
10
MHz |
100
MHz |
1
GHz |
|
SCI-2060-009 |
1 |
--- |
--- |
50 |
--- |
0.25 |
1.500 |
31.521 |
B |
70 |
70 |
70 |
70 |
70 |
70 |
70 |
|
SCI-2060-013 |
1 |
--- |
--- |
50 |
--- |
3.00 |
1.500 |
31.521 |
B |
--- |
33 |
54 |
70 |
70 |
70 |
70 |
|
SCI-2060-007 |
1 |
--- |
--- |
50 |
--- |
10.0 |
1.500 |
31.521 |
A |
15 |
29 |
35 |
42 |
55 |
70 |
70 |
|
SCI-2060-014 |
1 |
--- |
--- |
50 |
--- |
10.0 |
1.500 |
31.521 |
B |
15 |
29 |
35 |
42 |
55 |
70 |
70 |
|
SCI-2160-011 |
1 |
--- |
--- |
100 |
--- |
1.00 |
1.500 |
31.521 |
B |
12 |
52 |
70 |
70 |
70 |
70 |
70 |
|
SCI-2160-012 |
1 |
--- |
--- |
100 |
--- |
2.00 |
1.500 |
31.521 |
B |
--- |
33 |
56 |
70 |
70 |
70 |
70 |
|
SCI-2160-013 |
1 |
--- |
--- |
100 |
--- |
3.00 |
1.500 |
31.521 |
B |
--- |
24 |
54 |
70 |
70 |
70 |
70 |
|
SCI-2160-014 |
1 |
--- |
--- |
100 |
--- |
10.0 |
1.400 |
31.521 |
B |
12 |
25 |
32 |
42 |
55 |
70 |
70 |
|
SCI-2360-011 |
1 |
--- |
-- |
300 |
125 |
1.00 |
0.500 |
31.521 |
B |
--- |
48 |
70 |
70 |
70 |
70 |
70 |
|
SCI-2360-006 |
1 |
--- |
--- |
300 |
125 |
3.00 |
0.500 |
31.521 |
A |
--- |
12 |
38 |
70 |
70 |
70 |
70 |
|
SCI-2360-007 |
1 |
--- |
--- |
300 |
125 |
10.0 |
0.500 |
31.521 |
A |
5 |
18 |
24 |
34 |
55 |
70 |
70 |
|
SCI-2360-014 |
1 |
--- |
--- |
300 |
125 |
10.0 |
0.500 |
31.521 |
B |
5 |
18 |
24 |
34 |
55 |
70 |
70 |
