12-28 & 12-32螺装(孔径5.79mm) Pi型电路 |
|
|
|
|
|
12-28 & 12-32螺装(孔径5.79mm) Pi型电路
|
型号 |
M15733
军标号 |
图
号 |
额定电压
125℃ |
电流
Amp |
最小
电容量 |
A
mm |
B
mm |
最小插入损耗（dＢ） |
|
|
1
MHz |
3
MHz |
10
MHz |
30
MHz |
100
MHz |
300
MHz |
1
GHz |
10
GHz |
|
|
DC |
AC |
|
|
51-709-013 |
--- |
3 |
50 |
-- |
10 |
0.1µF |
1.02 |
11.10 |
10 |
40 |
52 |
70 |
70 |
70 |
70 |
70 |
|
|
SCI-3303-000﹡ |
--- |
2 |
50 |
-- |
10 |
0.15F |
0.81 |
6.35 |
12 |
43 |
68 |
70 |
70 |
70 |
70 |
70 |
|
|
51-709-015 |
61-0009 |
3 |
70 |
-- |
10 |
0.012µF |
0.81 |
11.94 |
-- |
-- |
-- |
-- |
65 |
65 |
65 |
65 |
|
|
1216-001 |
-- |
3 |
70 |
-- |
10 |
0.050µF |
0.81 |
11.89 |
15 |
20 |
60 |
65 |
75 |
75 |
75 |
75 |
|
|
1270-016﹡ |
--- |
2 |
100 |
-- |
10 |
5500pF |
0.81 |
6.35 |
-- |
7 |
20 |
35 |
65 |
70 |
70 |
70 |
|
|
1270-025 |
--- |
2 |
100 |
-- |
10 |
5500pF |
0.81 |
5.97 |
-- |
7 |
20 |
35 |
65 |
70 |
70 |
70 |
|
|
1201-066 |
-- |
1 |
100 |
-- |
10 |
5500pF |
0.81 |
-- |
-- |
7 |
20 |
40 |
68 |
70 |
70 |
70 |
|
|
51-714-055﹡ |
61-0011 |
2 |
100 |
-- |
10 |
5500pF |
0.81 |
5.97 |
-- |
7 |
20 |
-- |
65 |
70 |
70 |
70 |
|
|
51-714-054﹡ |
61-0010 |
2 |
100 |
-- |
10 |
5500pF |
0.81 |
6.35 |
-- |
7 |
20 |
-- |
65 |
70 |
70 |
70 |
|
|
51-714-053﹡ |
61-0007 |
2 |
100 |
70 |
10 |
5500pF |
0.81 |
6.35 |
-- |
7 |
-- |
-- |
65 |
70 |
70 |
70 |
|
|
51-714-058﹡ |
-- |
2 |
100 |
-- |
10 |
0.025µF |
1.02 |
6.35 |
10 |
15 |
40 |
60 |
70 |
70 |
70 |
70 |
|
|
51-714-056 |
61-0012 |
6 |
100 |
-- |
10 |
0.025µF |
0.81 |
5.97 |
-- |
-- |
-- |
-- |
65 |
65 |
65 |
65 |
|
|
SCI-3313-000﹡ |
-- |
2 |
100 |
-- |
10 |
0.10µF |
0.81 |
6.35 |
10 |
40 |
65 |
70 |
70 |
70 |
70 |
70 |
|
|
51-719-022 |
-- |
1 |
200 |
-- |
10 |
1300pF |
1.02 |
-- |
-- |
-- |
5 |
10 |
35 |
60 |
70 |
70 |
|
|
1201-052 |
-- |
5 |
200 |
-- |
10 |
3000pF |
0.81 |
-- |
-- |
-- |
5 |
15 |
45 |
45 |
70 |
70 |
|
|
1201-054 |
-- |
1 |
200 |
-- |
10 |
3000pF |
0.81 |
-- |
-- |
-- |
5 |
15 |
45 |
45 |
70 |
70 |
|
|
51-714-001﹡ |
-- |
2 |
200 |
-- |
10 |
3000pF |
0.81 |
6.35 |
-- |
-- |
5 |
15 |
43 |
60 |
70 |
70 |
|
|
1270-024 |
-- |
2 |
200 |
-- |
10 |
3000pF |
0.81 |
5.97 |
-- |
-- |
5 |
15 |
45 |
45 |
70 |
70 |
|
|
51-714-003﹡ |
-- |
2 |
200 |
-- |
10 |
3000pF |
0.81 |
5.97 |
-- |
-- |
5 |
15 |
43 |
60 |
70 |
70 |
|
|
1270-009 |
-- |
2 |
200 |
-- |
10 |
3000pF |
0.81 |
6.35 |
-- |
-- |
5 |
15 |
45 |
45 |
70 |
70 |
|
|
51-719-053** |
61-0001 |
5 |
200 |
140 |
10 |
3000pF |
0.81 |
-- |
-- |
-- |
-- |
-- |
45 |
-- |
70 |
70 |
|
|
51-719-054﹡ |
61-0002 |
1 |
200 |
140 |
10 |
3000pF |
0.81 |
--- |
--- |
--- |
--- |
--- |
45 |
45 |
70 |
70 |
|
|
51-714-051﹡ |
61-0005 |
2 |
200 |
140 |
10 |
3000pF |
0.81 |
6.35 |
--- |
--- |
--- |
--- |
45 |
45 |
70 |
70 |
|
|
51-719-023﹡ |
43-0001 |
5 |
200 |
140 |
10 |
3000pF |
0.81 |
--- |
--- |
--- |
--- |
--- |
--- |
45 |
45 |
45 |
|
|
51-714-052﹡ |
61-0006 |
2 |
200 |
140 |
10 |
3000pF |
0.81 |
5.97 |
--- |
--- |
--- |
--- |
45 |
45 |
70 |
70 |
|
|
51-714-004﹡ |
-- |
2 |
200 |
--- |
10 |
5500pF |
0.81 |
5.97 |
--- |
7 |
14 |
35 |
60 |
70 |
70 |
70 |
|
|
51-719-021 |
-- |
1 |
200 |
--- |
10 |
5500pF |
1.02 |
--- |
--- |
7 |
14 |
30 |
50 |
65 |
65 |
65 |
|
|
51-714-002﹡ |
-- |
2 |
200 |
--- |
10 |
5500pF |
0.81 |
6.35 |
--- |
7 |
14 |
35 |
60 |
70 |
70 |
70 |
|
|
SCI-3323-000﹡ |
-- |
2 |
200 |
115 |
10 |
0.012µF |
0.81 |
6.35 |
--- |
--- |
27 |
30 |
70 |
70 |
70 |
70 |
|
|
1221-001 |
-- |
4 |
300 |
--- |
10 |
5500pF |
0.81 |
11.10 |
--- |
--- |
15 |
30 |
65 |
70 |
70 |
70 |
|
|
51-709-004 |
46-0001 |
4 |
300 |
--- |
10 |
5500pF |
0.81 |
11.10 |
--- |
--- |
--- |
--- |
65 |
70 |
70 |
70 |
|
|
1201-086 |
-- |
1 |
350 |
--- |
10 |
2500pF |
0.81 |
--- |
--- |
--- |
5 |
10 |
50 |
50 |
65 |
65 |
|
|
51-719-011 |
-- |
1 |
500 |
--- |
10 |
3000pF |
1.02 |
--- |
--- |
--- |
12 |
20 |
45 |
60 |
60 |
60 |
|
﹡表示提供的引线如图7所示 |
|
|
|
|
|
