不锈钢螺旋管屏蔽衬垫
(镀锡不锈钢)

直径
英寸（mm）

标准弹力*

中等弹力

低弹力

深度 (L)
+.002"(.051)
-.000"(.000)

宽度 (G)
+.007"(.178)
-.005"(.127)

宽度(W)
+.000"(.000)
-.002"(.051)

.034" ± .002"
（0.86 ±.051）

TNI-02

TNM-02 NC

--

.023"
(.584)

.046"
(1.158)

.033"
(.838)

.047" ± .002"
(1.19 ±.051)

TNI-03

TNM-03 NC

--

.035"
(.889)

.063"
(1.600)

.063" ± .003"
(1.60 ± .076)

TNI-04

TNM-04 NC

TNL-04 NC

.046"
(1.168)

.060"
(1.524)

.070" ± .003"
(1.77± .076)

TNI-.070

TNM-.070 NC

TNL-.070 NC

.053"
(1.346)

.094"
(2.388)

.067"
(1.702)

.078" ± .003"
(1.98± .076)

TNI-05

TNM-05 NC

TNL-05 NC

.059"
(1.499)

.109"
(2.769)

.075"
(1.905)

.094" ± .004"
(2.39± .102)

TNI-06

TNM-06 NC

TNL-06 NC

.070"
(1.778)

.125"
(3.175)

.090"
(2.286)

.103" ± .004"
(2.62± .102)

TNI-.103

TNM-.103 NC

TNL-.103 NC

.077"
(1.956)

.141"
(3.581)

.099"
(2.515)

.109" ± .004"
(2.77± .102)

TNI-07

TNM-07 NC

TNL-07 NC

.082"
(2.083)

.156"
(3.962)

.105"
(2.667)

.125" ± .004"
(3.18± .102)

TNI-08

TNM-08 NC

TNL-08 NC

.094"
(2.388)

.171"
(4.343)

.121"
(3.073)

.139" ± .005"
(3.53± .127)

TNI-.139

TNM-.139 NC

TNL-.139 NC

.104"
(2.642)

.187"
(4.750)

.134"
(3.404)

.141" ± .005"
(3.58± .127)

TNI-09

TNM-09 NC

TNL-09 NC

.105"
(2.667)

.187"
(4.750)

.136"
(3.454)

.172" ± .005"
(4.37± .127)

TNI-11

TNM-11 NC

TNL-11 NC

.128"
(3.251)

.234"
(5.944)

.165"
(4.191)

.187" ± .006"
(4.75± .152)

TNI-12

TNM-12 NC

TNL-12 NC

.140"
(3.556)

.250"
(6.350)

.181"
(4.597)

.250" ± .007"
(6.35± .178)

TNI-16

TNM-16 NC

TNL-16 NC

.185"
(4.699)

.343"
(8.712)

.240"
(6.096)

.312" ± .009"
(7.92± .229)

TNI-20

TNM-20 NC

TNL-20 NC

.234"
(5.944)

.422"
(10.719)

.300"
(7.620)

材料

弹力

无电镀

镀锡/铅

RoHS 镀锡

边缘 镀锡

不锈钢

标准
中等
低

参考上表

（型号前不带T）

TNI (default)
TNM
TNL

IWNI
IWNM
IWNL

参考铍铜

螺旋管屏蔽衬垫
